v Housing Material :

v 外壳材料:

Phenolic Resin (RF)

电木

v Standard Rating

v 额定功率标准

[ UL & CUL ]                             125V AC 45A

[ TUV ]                                      250V AC 45A or 60A

[ CQC ]                                     250V AC 45A

v Number of Automatic Cycles for each Automatic Action:

v 自动循环动作寿命:

[ UL & CUL ]                             6,000 cycles

[ TUV ]                                      3,000 cycles

[ CQC ]                                      6,000 cycles

v Maximum Temperature  :

v 最高工作温度  :

[ UL & CUL ]                             140°C

[ TUV ]                                      150°C

[ CQC ]                                     150°C

v Temperature Setting Range  :

v 温度控制设定范围  :

[ UL & CUL ]                              0°C - 140°C

[ TUV ]                                       50°C - 150°C

[ CQC ]                                       30°C – 150°C

v Tolerance of Operation Range :

v 操作温度公差范围 :

± 5℃~± 10℃

v Switching Differential :

v 温差：

10 – 50K depending on mounting and design

依据安装及设计定为10 – 50K不等
